Home / Baling Machines / Automatic Balers / CB-M Channel Balers

CB-M Channel Balers

Our most popular series, typically producing bales of 400-600kg at throughputs of up to 15 tph.

The Durapac CB-M range of fully automatic balers are perfect for waste and recycling companies, manufacturing plants, warehouses and distribution centres, etc. with medium to high volumes of materials for baling and recycling.

With their 1050 x 2100mm feed aperture and high press force that, depending on motor/power choice and materials, will process 6-15 tonnes per hour, producing dense bales weighing up to 600kg.

Key features

  • Medium footprint
  • 400-600kg bale weights
  • 1100 x 750 x 1000~1500mm bale size
  • 6-15 tph throughput
  • 1050 x 2100mm feed aperture
  • 70/90/120t press force
  • 30/45/2x30kW motor options
  • 20 years+ proven manufacturer
  • Hardox/castellated floor
  • Fully CE compliant
Bale Weights
400kg - 600kg
Material To Recycle
Cardboard / Paper, PET Bottles / Drinks Cans, Plastic / Film
Weekly Volume

The Durapac CB-M Channel Baler is a high quality, continuous feed, fully automatic baler with a large infeed aperture and high press force that, depending on motor/power choice and materials, will process typically 6-15 tph of cardboard, paper, polythene film, hard plastics, PET bottles, drinks cans, MSW/RDF/SRF, etc.

Its heavy duty build quality, components and proven design ensure reliable performance, low OPEX and a long working life.

The Human interface/control panel incorporates full error diagnostics, intuitive controls and multi material programming. This guarantees easy operation, troubleshooting and simple maintenance.

Ideal for material baling at sites such as waste and recycling facilities, MRFs, manufacturing plants, large printing companies, distribution centres/warehouses, etc. the Durapac CB-M Channel Baler offers easy and safe operation and high performance.

In Summary

  • 20 years+ proven manufacturer
  • Hardox/castellated floor for long and durable life
  • Bespoke machine build specific to your needs
  • Low maintenance, low OPEX design
  • Unique tying system prevents wire slip and jams
  • Horizontal/vertical/cross tie options
  • Easy access press ram
  • Manufactured from Japanese steel
  • Mitsubishi PLC
  • Parker hydraulics
  • Human operator interface/controls
  • Remotely programmable
  • Interlocked maintenance access doors
  • Raised bale floor for ease of cleaning
  • Fully CE compliant
  • Wide range of loading hoppers/chutes
  • Over side or rear feed conveyors – in or above floor
  • PET piercers and newspaper/magazine preconditioners
  • Automatic de-blocking system
  • Wheelie bin tippers/safety cages
  • Wire coils or formers
  • Vertical/horizontal/cross tie
  • Various bale run out tables
  • Hardox steel upgrades

All models come with options of horizontal, vertical or cross wire tie.

Press force 70/90/120t
Motor power 30/45/2x30kW
Bale size (W x H x L) 1100 x 750 x 1000~1500mm
Bale density 400-600kg
Main cylinder diameter 224/250 x 2700mm
Opening size 1050 x 2100mm
Layout dimension 9200 x 3100 x 3300mm
Number of wire ties 5 vertical, 4 horizontal
Oil reservoir 1200/1500/2000L
Throughput approx 6-10/8-12/10-15 tonnes per hour
Machine weight 17/18/19t
